Carbon fiber foot

  • Spherical Ankle Shock-absorbing Prosthetic Carbon Fiber foot

    Spherical Ankle Shock-absorbing Prosthetic Carbon Fiber foot

    Product name: spherical ankle shock-absorbing carbon fiber prosthetic foot
    Item NO.: 1CFH-002
    Size Range: 22cm ~ 27cm, interval 1cm
    Heel height: 10cm ~ 15mm
    Structural height: 155mm (shoe size 25cm)
    Product weight: 610g (shoe size 25cm, without foot cover)
    Load range: 85-100kg
  • Prosthetic Foot High Ankle Carbon Fiber Elastic Foot with TI adaptor

    Prosthetic Foot High Ankle Carbon Fiber Elastic Foot with TI adaptor

    1.ISO 13485/CE passed, CE certificate, SGS Field certified.
    2.Minimum order Quantity: 1pcs.
    3.Sample is available, but sample cost and ship cost paid by buyer.
    4.Delivery Time: after receiving payment 2-3 days.
    5.Payment Term: T/T 100% At Advance.
  • Syme Carbon Fiber Foot

    Syme Carbon Fiber Foot

    Product name Syme Carbon Fiber Foot
    Item NO. 1SCF-001

    Size Range 22~27cm
    Heel height Syme Foot
    Product weight 230g
    Load range 85~100kg
    Product description Prosthetic foot specially designed for Syme amputees and patients with long leg stumps, suitable for all kinds of terrain and pavement, users are more relaxed and natural in walking.
    Main features The feet are made of carbon fiber, and the metal parts are titanium alloy, which is light in weight, strong in strength, resistant to corrosion and durable.
  • Low Ankle Carbon Fiber Elastic Foot with aluminum adapter

    Low Ankle Carbon Fiber Elastic Foot with aluminum adapter

    Specification
    Product name
    Low Ankle Carbon Fiber Elastic Foot with aluminum adapter
    Item NO.
    1CFL-001
    Size Range
    22cm~27cm, interval:1cm
    Heel height
    10mm~15mm
    Structural height
    78mm
    Product weight
    280g (size:24cm)
    Load range
    85-100kg
    Product description
    Carbon fiber energy storage foot is a stable light weight foot designed for life and work needs.It is developed by researchers
    from the Institute of technology, Peking University.We have complete independent intellectual property rights of which from
    prototype design, simulation experiment, carbon fiber laying technology to later stage process experiment.using Aeronautical
    carbon fiber material and molding process.
    When walking, carbon fiber energy storage feet store the kinetic energy and potential energy of the human body to provide the
    optimal cushioning and shock absorption effect. When it is necessary to exert force, the carbon fiber energy storage feet release
    the stored energy, pushing the body forward, and helping the user save his strength. Get a natural gait.
    Better curves, closer to human needs, make rolling smoother and more natural gait.
    More suitable for Asian weight rating design, more suitable for Chinese wearing.
    Main features
    Compared to the traditional prosthetic material, it has high strength, good elasticity, light weight, long service life etc.
    advantages.
  • Chopat Carbon Fiber Foot

    Chopat Carbon Fiber Foot

    Chopat Carbon Fiber Foot

    Product name

    Chopat carbon fiber foot

    Item NO.

    1CCF-001

    Size Range

    22cm~27cm

    Heel height

    Chopat foot

    Product weight

    220g

    Load range

    85-100kg

    Product description

    The chopart footplate is specially designed for partial foot amputation. It is not only fulfilled visually requirements of the

    needs but also fully functional. The carbon fiber technology provides energy storage and return during ambulation, and split toe

    design enables patients to walk on uneven ground situations. The footplate can be adhere attached to the prosthetic socket.

    Main features

    1.With a certain degree of shock absorption
    and universal function.
    2.Special carbon fiber receiving cavity and carbon
    fiber foot bonding technology realize the
    assembly of extra-long Chorpart residual limbs.

  • Low Ankle Carbon Fiber Elastic Foot with titanium adapter

    Low Ankle Carbon Fiber Elastic Foot with titanium adapter

    Specification
    Product name
    Low Ankle Carbon Fiber Elastic Foot with titanium adapter
    Item NO.
    1CFL-002
    Size Range
    22cm~27cm, interval:1cm
    Heel height
    10mm~15mm
    Structural height
    78mm
    Product weight
    280g (size:24cm)
    Load range
    100-120kg
    Product description
    Carbon fiber energy storage foot is a stable light weight foot designed for life and work needs.It is developed by researchers
    from the Institute of technology, Peking University.We have complete independent intellectual property rights of which from
    prototype design, simulation experiment, carbon fiber laying technology to later stage process experiment.using Aeronautical
    carbon fiber material and molding process.
    When walking, carbon fiber energy storage feet store the kinetic energy and potential energy of the human body to provide the
    optimal cushioning and shock absorption effect. When it is necessary to exert force, the carbon fiber energy storage feet release
    the stored energy, pushing the body forward, and helping the user save his strength. Get a natural gait.
    Better curves, closer to human needs, make rolling smoother and more natural gait.
    More suitable for Asian weight rating design, more suitable for Chinese wearing.
    Main features
    Compared to the traditional prosthetic material, it has high strength, good elasticity, light weight, long service life etc.
    advantages.
  • Prosthetic Leg High ankle Prosthetic Foot Carbon Fiber With Titanium Adapter

    Prosthetic Leg High ankle Prosthetic Foot Carbon Fiber With Titanium Adapter

    Specification
    Product name
    High Ankle Carbon Fiber Elastic Foot with titanium adaptor
    Item NO.
    1LVCF-001
    Size Range
    22cm ~ 27cm, interval 1cm
    Structural height
    170 mm(25 size)
    Product weight
    625g (shoe size 25 cm)
    Load range
    125 kg
    Product description
    Compared to the traditional prosthetic material, it has high strength, good elasticity, light weight, long service life etc.
    advantages.
    Better curves, closer to human needs, make rolling smoother and more natural gait.
    More suitable for Asian weight rating design, more suitable for Chinese wearing.
    Main features
    1、split toe design
    the upper and lower foot boards are designed with split toe type,which can produce different elastic deformation with the change
    of road conditions and make it more comfortable to wear.
    2、Low structure height
    low structure height provides a wider range of use and a wider trial population.
    3、High quality material
    Titanium alloy connector,Aeronautical carbon fiber raw materials.
